Exceptional Image Quality
- High resolution up to 508 DPI
- 14-bit grayscale processing for superior contrast
- Uniform optical density for accurate diagnosis
Delivering sharp, consistent, and diagnostic-grade images every time.
High-Speed Performance
- Prints 75–100 films per hour (14” x 17”)
- First print output in < 80 seconds
- Fast & High-Quality dual printing modes
Perfect for high patient volume environments.
Intelligent Adaptive Technology
- Built-in optical densitometer
- Automatic heating curve adjustment
- Ensures stable image density across different films
Result: No compromise in image clarity, regardless of usage conditions.
Advanced & Secure Architecture
- Latest SoC chipset for enhanced performance
- Strong data security from software to hardware
- Linux-based system for stability and control
Reliable & Jam-Free Operation
- Anti-static brush technology reduces film sticking
- Smart suction pickup system
- Auto-calibration film separator
Designed to minimize downtime and avoid film jams, even in humid conditions.
Imaging & Performance
- Technology: Dry Thermal Imaging
- Resolution: 508 DPI
- Grayscale: 14-bit processing
- Print Speed: Up to 100 sheets/hour
- First Print Time: < 80 seconds
Film Handling
- Film Sizes:
- 8” x 10”
- 10” x 12”
- 11” x 14”
- 14” x 17”
- Dual Film Trays: 100 sheets each
- Film Type: Dye / Silver Salt
System & Connectivity
- Interface: Ethernet (RJ-45)
- Protocol: DICOM Compatible
- Display: 8-inch Touch Panel
- OS: Linux-Based System
Physical Specifications
- Dimensions: 595 × 665 × 597 mm
- Weight: 85 kg
- Power Supply: 100–240V AC
Key Benefits
- Consistent diagnostic image quality
- Faster patient reporting
- Low maintenance & high durability
- Seamless integration with PACS/DICOM systems
- Ideal for medium to large diagnostic setups
Made in India | CDSCO Approved
The ERAY Thermal Printer is proudly manufactured in India and complies with key medical safety standards, making it a trusted solution for healthcare providers.
Applications
- Hospitals & Multi-Specialty Centers
- Diagnostic Imaging Centers
- Radiology Labs
- Teleradiology Setups
